Electric Heating Rotational Mold Built-in Heating Elements for Plastic Water Tank Custom Made

Brand Name:	YOUGE
Model Number:	EH-W02
MOQ:	1 Set
Price:	USD 4,000-18,000 / Set
Payment Terms:	T/T,L/C
Supply Ability:	30 Sets per Month

Detail Information

Product Description

Ratings & Reviews

Detail Information

Place of Origin:

Jiangsu, China

Certification:

ISO 9000

Mold Material:

Aluminum Alloy 5083

Heating Element:

Stainless Steel 304 Heating Tubes

Temperature Range:

50-280 °C

Temperature Control:

PID Digital Controller

Heating Power:

Customizable

Voltage:

380V Three-phase

Mold Thickness:

10mm

Application:

Plastic Water Tank, Cooler, Buoy

Design Software:

SolidWorks / UG

Warranty:

12 Months

Packaging Details:

Export wooden case with foam protection

Supply Ability:

30 Sets per Month

Highlight:

Compact Electric Heating Mold

Precision Temperature Control

Large Water Tank Mold

Product Description

Electric Heating Rotational Mold for Plastic Water Tank

This electric heating rotational mold embeds stainless steel 304 heating tubes into an aluminum alloy 5083 mold body, delivering even heating and low energy consumption for plastic water tank rotomolding. Custom made to your drawings.

Key Features

Compact structure with built-in electric heating elements, no external oven required
Precision PID temperature control keeps the mold surface stable within ±1 °C
Low energy consumption reduces production cost per piece
Aluminum alloy 5083 body with high thermal conductivity and long service life
Custom size, heating power and voltage available

Technical Parameters

Mold Material	Aluminum Alloy 5083
Heating Element	Stainless Steel 304 Heating Tubes
Temperature Range	50-280 °C
Temperature Control	PID Digital Controller
Heating Power	Customizable
Voltage	380V Three-phase
Mold Thickness	10mm
Application	Plastic Water Tank, Cooler, Buoy

Applications

Suitable for rotomolding plastic water tanks, coolers, buoys and other hollow products requiring uniform wall thickness and stable heating.

Customization & Support

YOUGE provides full custom mold design and engineering services from our factory in Jiangsu, China. Product training, maintenance and on-site technical support are available.

Packing & Shipping

Export wooden case with foam protection. Delivery within 30-45 days after design confirmation.
